Lens calculator for
Note: Individual variations of the field of view could exist, for example due to back focus adjustment and lens distortion. Plan with margins.
Select units:
Choose range:
Select resolution:
Choose range:
It is not possible to replace the supplied lens on
AXIS P3353 6mm
.
The housing limits the field of view to X 吏�.
The supplied lens does not support the selected scene size at the given distance.
It is not possible to replace the supplied lens on AXIS P3353 6mm .
Select camera model by pressing the Change button.
If the camera uses a varifocal or zoom lens, a calculator icon is displayed in the top right corner of the Scene dimensions and resolution , Distance and Focal length fields. Click the calculator icon next to the value you wish to calculate.
Enter your given values into the Scene dimensions and resolution fields, or drag the Distance or Focal length sliders. The results are continuously updated.
Note: The scene width and scene height are kept in proportion by the camera's aspect ratio. Use the Resolution popup to select a different aspect ratio, if available.
Note: The resolution is determined by the horizontal resolution of the camera sensor and the scene width. Therefore resolution will always change when scene width is changed, and scene width will always change when resolution is changed, regardless of camera distance and camera focal length.
Note: The lens calculator displays a warning if the calculated focal length is outside the range supported by the camera's lens.
Select metric or imperial units using the Units link next to the distance slider.
Change the range for the Distance and Focal length sliders using the Range links.
